| OPERATIONAL |
|
 |
Light Source
Depth of Field
Scan Pattern
Scan Rate
Number of Scan Lines
Minimum Bar Width
Print Contrast
Indicators (LED)
Beeper Operation
System Interfaces |
630 nm visible LED
2,088 pixels CCD
0 – 20 mm (UPC/EAN 100%, PCS=90%)
80 mm
100 scans per second
0.125 mm (5 mil) (0.1 mm actually)(Code 39, PCS=90%, contact)
30% @ UPC/EAN 100%
Blue LED
Programmable tone & beep time
Keyboard, RS-232C, HID USB, wand |
|
| PHYSICAL |
|
|
Dimensions
Weight
Cable |
(L)169.7 × (W)88.8 × (H)61.5 mm (device only)
100 g (cable excluded)
Standard 2.0M straight |
|
| POWER |
|
|
Input Voltage
Operating Current |
5 VDC ±10%
70 mA typical |
|
| REGULATORY |
|
| EMC |
CE & FCC DOC compliance, VCCI, BSMI |
|
ENVIRONMENTAL
|
|
|
Operating Temperature
Storage Temperature
Humidity
Light Levels
Drop Durability |
0°C – 50°C (32°F – 122°F)
-20°C – 60°C (-4°F – 140°F)
5% – 95% RH (non-condensing)
Max. 3,000 Lux (fluorescence)
Designed to withstand 1.5M drops |
